Audit Logons with Extended Events

Some time ago, I wrote an article for SQL Server 2008 to help determine the use of the server since SQL Server 2008 was reaching End Of Life. In that article, I shared a reasonable use of server side trace to capture all of the logon events to the server. Afterall, you have to find out the source of connections and who is using the server if you need to migrate it to a newer SQL Server version. You can read that article here.

Soon after, from various sources, I received requests on how to perform a logon audit using the more preferred, robust, venerable, awesome tool called Extended Events (XEvents). In response, I would share a login audit session to each person. In this article, I will share my login audit solution and give a brief explanation. I use a solution like this on more than 90% of my client servers and I find it highly useful.

Auditing Logons

The Events to capture SQL Server logon/logoff activities were not a part of the original release of XEvents in 2008. The requisite events did not become available until SQL Server 2012. Why mention SQL Server 2008 at all given it has reached its End of Life you may ask? Well, as luck would have it, there are still plenty of 2008/R2 instances out there in the world that are yet to be upgraded still. So, it is useful to continually point it out. This session, and this information, does NOT apply to anything prior to SQL Server 2012.

The events in XEvents that we need happen to be called: sqlserver.login and sqlserver.logout. Here is a little more info on those events along with a query that can retrieve the details being shown here.

As shown in the preceding image, there are two events of interest that are needed for auditing logon events – sort of. These events are only useful to capture the successful connection (or connection pooling reuse connections) and the logoff events. To take this a step further and capture the failed logins, we can also use an Event that was available in 2008, error_reported. The use of the logout event would be an optional event in this case but could be of use during the troubleshooting under certain circumstances.

Focusing on the login and error_reported events, I have two very useful XEvent Sessions I like to use for my client servers. First part of the audit logon solution is the audit of successful logins with this XEvent Session.

Next, I like to use a separate session for the failed logins. This makes it easy to keep the audit files separate and only share the necessary files to others (e.g. only the failed logins instead of giving them both successful and failed which may be way too much information). In addition, I like this method because it makes searching the audit files easier and more focused.

In this second session, I have the predicate defined such that I will only get the failed login events. Funny thing about this, I can often catch 3rd party vendors trying to login to client systems in very odd ways (including putting the password into the user name box which in turn causes the password to be stored in clear text in the error log).

Could these sessions be combined into a single all-purpose session? Sure! That is up to your discretion. I prefer the separate sessions for ease of management and review.

The Extra Mile

Let’s say we wanted to go ahead and add the logout event to our session, we can then proceed with a slight modification to the successful login session so that it would look something like the following.

And, to show what might occur with this session, I can see data similar to this for the logout event.

See how easy that is!

The Wrap

This article has shown how to audit the logon events for SQL Server 2012 and beyond through the use of XEvents. It also happens to be an excellent follow up to another recent article – here. An essential function of any DBA is to have a clear understanding of the activity (logons) that is occurring on the servers. This audit session will help you do exactly that!

Through the power of XEvents, we can accomplish a great many things and reach extensive insights into our database footprint. This post is just one of many in the XE Series, of which you can read more – here.

In addition, this post is similar to many in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

CRM Data Source Connection Error

Working through some security modernization recently with a client I ran into a fun little nugget. What we were trying to accomplish was to make the service accounts being used more secure through the use of Managed Service Accounts.
Making the change was fairly easy and all of our services seemed to start up swimmingly. SQL Server was running perfectly fine. Even when we got to SSRS and applied the change to the Service account via SSRS Configuration Manager, things went smooth.

After ensuring the services all started came the task of validation. From a sysadmin perspective we often figure the validation process means looking through the tools we know and sometimes we don’t know what to do via the application to validate functionality. For this we more or less rely on the end-users. While waiting for the end-users to perform their validations, we resort to the tools known best to us – SSMS etc.

In the case of testing reports, one may attempt to use the Report Manager url (or report server url). When opening reports, you may see that everything is working correctly through that tool. So, you continue to wait for the end-user to validate. Eventually they say it all looks good only to report back a week later that nothing is working and now you are stuck trying to figure out what to do to resolve the problem.

SSRS Service Account Needs PrivUserGroup

This is particularly interesting given everything worked just fine before the service account change and given that the only thing that changed was the service account (via Reporting Services Configuration Manager). Nothing changed with the execution account (an execution account was not actually employed in this configuration at any point).

We also determined that nothing was necessary to be changed with the CRM’s “SRS Data Connector”. What is the next best thing? Well, time to take a look into the logs and try to find some clues there. Perusing the logs, I was able to find a couple of key indicators. Here are the two enlightening errors.

First error:

“Cannot create a connection to data source ‘CRM’.”

Better, more verbose exception that broke the case wide open:

“Immediate caller <SQL Server Reporting Services Service Account> has insufficient privilege to run report as user <SID>”

Googling for these errors revealed a lot of information about the errors in the event an Execution Account for SSRS was being used. That scenario didn’t apply but it did give a hint at what to look at next. Comparing the previous service accounts permissions in Active Directory to the new service accounts permissions we found the “PrivUserGroup” permission was missing. This permission was the exact permission mentioned in all of the other articles. Adding that permission immediately solved the issue for the end-users and their ability to run reports via the CRM application.

The Wrap

This article takes us to the edge with a couple of CRM related errors after changing the service account to a more secure Managed Service Account. Despite the CRM reports working properly within Report Manager (via SSRS), the reports would fail in CRM.

Comparing the permissions for the old service account versus the new service account shed a bright light on the problem indicating a missing permission. PrivUserGroup is essential to proper report functionality and should be added to either your execution account or your SSRS service account.

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

Ad Hoc Queries Disabled

DBAs and ad hoc queries sometimes go together like oil and water. While we may prefer to avoid the ad hoc queries, sometimes it is the best method to achieve a task.

What exactly is an ad hoc query though? An ad hoc query is a query that should serve a single use purpose (not always the case), is routinely unplanned and quite possibly was untested (again, not always the case). Sometimes, however, the definitions of ad hoc don’t fully apply to queries in SQL Server. One such case is through the use of dynamic type queries and queries issued to linked servers via openrowset.

In my experience, queries used against a linked server and using the openrowset functionality is typically more of a prepared statement. However, it is treated as an ad hoc query. As such, you may encounter an error you may not have been expecting.

Msg 15281, Level 16, State 1, Line 161
SQL Server blocked access to STATEMENT ‘OpenRowset/OpenDatasource’ of component ‘Ad Hoc Distributed Queries’ because this component is turned off as part of the security configuration for this server. A system administrator can enable the use of ‘Ad Hoc Distributed Queries’ by using sp_configure. For more information about enabling ‘Ad Hoc Distributed Queries’, search for ‘Ad Hoc Distributed Queries’ in SQL Server Books Online.

This article will help show how to resolve for this error so your queries may go on as intended.

Ad Hoc

Let’s first take a look at a pretty typical type of query I use routinely to check various things on my lab servers.

This is a query that I use (or something like it) to retrieve various Extended Events data from different lab servers. Notice, I use the openrowset method in order to query my linked server. If I do not have the server configured for ad hoc distributed queries then I will receive the error previously noted. The solution for that error is to enable the setting. We can do that via the following query.

Once enabled, then the openrowset queries will work across linked servers. This needs to be enabled on the server that is local in order to send the ad hoc query across to the remote server. With the setting now enabled, running the query that threw the error (from above) now returns the follow results.

The Wrap

This article took a look at an error that may occur depending on your use of linked servers and the use of openrowset. Documentation states that this is something that should be done infrequently and alludes to the issue being resolved through the use of linked servers. In my case, this crops up when using openrowset to query my linked servers. I find that using openrowset to query the linked server is far more reliable, efficient, and better performing. YMMV.

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

When Too Much is Not a Good Thing

In my previous article, I demonstrated some fun ways of locking down access for certain users to ensure they did not have data access while at the same time allowing them to review the database schema. The solution provided had the added benefit of reducing the chances that such a user could unknowingly cause a server outage.

In that solution, I showed the value of the “View Definition” permission. There are a couple of caveats to this permission that could lead to unwanted results.

It is these unwanted results that oft occur due to lack of attention to detail, use of internet examples, misunderstanding of the requirements; and always from granting way too much access. I am going to explore a couple of these erroneous methods and why they absolutely bug me.

You Get Everything!

Let’s start with the most common mis-step that I see. A user requests access to the database and the stand-in DBA takes the easy route. The easy route here is to grant the requester sa access, dbo access, and every other database and server role there is because it is easier to just tick the boxes.

This method of assigning permissions happens far too frequently. I have seen it in hundreds of databases for clients. I have also written about it here.

You see, once you grant somebody sa access, none of the rest of the permissions grants or denies matter. Sysadmin overrides everything! In this particular case, this would be way too much access for the user who just needs to see the schema. Be extremely careful about when and to whom you grant sysadmin access.

Next up in the realm of granting way too much access is the far too frequent practice of assigning the permissions to the public role in each database. I have written about this practice as well – here and here. This one really gets my ire. Granting permissions to the public role starts to cross into the realm of high risk and downright negligent. Let’s see how some internet examples demonstrate the solution to our problem with regards to the public role.

First, using the test user and role we created in the yesterdays article, let’s confirm that we do not have access to view definitions outside of the assigned role permissions.

After executing that query, I can confirm that the public role does not have the “View Definition” permission. Let’s now revoke the permission to the role and confirm no schema definitions could be viewed.

Now, knowing that the user and the role do not have permissions, let’s go ahead and assign permissions to the public role.

Just like magic, a user that should not be able to view schema definitions can now view information it is not supposed to see. This is a security problem. Just to confirm, let’s evaluate the principal permissions compared to the role permissions.

Keep this in mind as you go down the dark path to granting permissions to the public role. Just because it is easy doesn’t make it right. Similar note, you should proceed cautiously with scripts from the internet that suggest granting permissions to the Public role. They are wrong!

Finally, we down into the realm of “only slightly better” but still way over the top for the requirements. This last method uses the “VIEW ANY DEFINITION” way of granting permissions. Now the “ANY” key word actually scopes the permissions to every database on the instance. Let’s clean up the last example by revoking the permission to public so we have a blank slate.

With permissions, revoked, I will now grant View Any Defintion to the test user. Why? Well, because I don’t have that role created in every database (more on the benefits of that approach later). When setting this permission, it is server scoped so make sure you are in the master database else you chance seeing this error.

Msg 4621, Level 16, State 10, Line 22
Permissions at the server scope can only be granted when the current database is master

Yup, that just made my blood curdle a bit. Let’s check out the perms now in the DBA database (reminder that the scope of the permission change was the master database and is a server scoped change).

As we can see here, all databases now have the View Definition permission assigned to testvwdef. If there happens to be a sensitive database, you may have exposed yourself to a risk by doing this.

Performing the same tests as previously done would reveal similar results – except on a broader scope.

There are some caveats to help reduce this risk but they do not undermine the need to be responsible or the need to avoid using the “ANY” keyword. Recall that I granted the View Any to the individual user instead of the role? That was simply due to me not having that role in each database. If we grant permissions to roles, and the role does not exist in the master database while trying to grant permissions from that scope, then we see this nifty little message.

Msg 15151, Level 16, State 1, Line 25
Cannot find the login ‘BusinessViewDef’, because it does not exist or you do not have permission.

That is one measure to help prevent this over-permissioning problem. The next possible caveat is a minor stop-gap and can be easily overlooked should the user ever be added to the database in the future. For “Any” to work in its full splendor, the principal to which it was granted must have already been granted “connect” to the database.



The Wrap

This article has explored various different options for minimizing risk to over extending permissions to users. With a little planning and care, we can find various ways to fulfill user requests without compromising the environment.

Every now and then, it will require extra effort in trying to get the pertinent details from the requester. That said, with that extra effort you will find satisfaction and calm knowing your environment is secure and that you are providing quality service to your customers.

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

Who needs data access? Not You!

Does this sound at all familiar? A user submits a request stating they must have elevated access to a database. In your attempt to gather more information about the request, they must have access because so-and-so has elevated access and they are curious about the database.

The conversation doesn’t go quite as smoothly as that. In fact, it may take quite a lot of effort to squeeze that tiny bit of real information from the request.

After assembling that tidbit of information, you may find yourself choking back a scoff or three. “You need access because you want to explore the database?” Yeah I can hear the incredulity in your thoughts from here. At no point is this kind of “need” a legitimate reason to gain access to a database.

“I need elevated access!” Oh No you don’t!

Beyond the back and forth of the demand for access just to play around in the data and the DBA resisting the access in the best interest of the data and company, there may possibly be a middle ground that can be reached. I am not talking about creating a dummy database with obfuscated data. Nor am I talking about a dummy database with fake data.

Every now and then, this kind of request may cross your desk and all the requester is really trying to do is find some means of becoming familiar with the database. This can be ferreted out with some extra warnings and more discussions with the requester. Maybe the request really has nothing to do with the data and everything to do with just finding a way to get to know the schema because there is no documentation.

Given the plausibility of this need, there are many ways to grant the request – some may require more resources than others. Let’s suppose the user has absolutely no understanding of TSQL. With that minimal knowledge, you know there is likely to be many potential issues that could cause the database to be brought down and unusable. This is terrible if the affected database is in production. It is also very bad if the database is a non-prod database. Given this potential, you know you don’t want to grant any permission that implies read or write permissions in the database (if there is data present).

What if we could create a database without the data. Would that work? Absolutely that would work. This would in essence be a sandbox for the user and all responsibility for database issues could be directed back to the specific user. This is a fabulous solution if you have adequate resources for more databases/instances/servers to be created. There are multiple ways to create an empty database, but to ensure the best end-user experience considerations for database naming, resources, and potential impact to other databases must be acknowledged.

Personally, I prefer to maintain the same database name regardless of tier (dev, test, prod etc). This also applies to schema only types of databases where limited access would be granted. Changing database names on the users only breeds confusion and complicates code promotions. If you need to provide the same sort of solution for 30-40 or more databases, you can imagine what kind of confusion that would cause on a server where the actual data-filled databases actually exist (think dbcc clonedatabase types of solutions here where the cloned database must be named differently).

What to do? What to do?

Thankfully there is still at least one more entirely viable option that remains. We can use the power of security to achieve some semblance of the user want and still preventing the person from viewing the data or even causing performance issues.

Limiting access for prying eyes is fairly easy while still granting the opportunity to explore the database design. In SQL Server we have a permission called “View Definition” which will help us accomplish exactly this requirement. In preparation for this, one must determine the scope of the need. Generally speaking, this should be done on a per-database approach. There is a method to grant this for all databases on the server but that is a topic for another day. Once the scope is determined, it is time to proceed with the setup.

I prefer to take advantage of Roles within the database. This simplifies the future maintenance and management of the permissions. If a new principal needs the same permissions as Joe from accounting, then I just add the new user to the same role(s) as Joe – piece of cake.

With the Role created, user added to the role, and the “View Definition” permission granted to the role, we are ready to test.

First order of business is to connect with that new login we created (a SQL login was created and is used in this example, but the effects are the same with a Windows Login) as shown in the preceding image. After connected, let’s try some things.

The first test I want to perform is to confirm the user has no read access to data to ensure this permission does not grant extra access along the way.

Great! Select access to objects from this permission alone does not work. Now, let’s test the ability to view object definitions. First, let’s try via the object designer.

First we see a warning about not having enough permissions to save changes, which is good. After clicking OK on that warning, a new message pops up to remind us that the table is “read only”. Perfect! The permission we gave this user do not allow them to alter objects – just view them (as we would expect).

Seeing these results should also help confirm for us that I can browse the table definition directly in SSMS. Let’s take a gander from a TSQL approach.

Great, we can explore the table definitions etc with TSQL. That is of course a system stored procedure, so let’s try one more method.

Running this query, I will see results similar to this.

Knowing that we can run custom queries to explore the schema is almost comforting. It does confirm that we are able to query system objects (yes a select works here but this is read only object definition data). But does this mean the user can also see system data? Let’s try!

Excellent! So it seems we have a plausible option to keep the footprint small and minimize access to the data.

The Wrap

This article has explored various different options for reducing the access to data for users who “need” it. With a little planning and care, we can find various ways to fulfill user requests without compromising the environment.

Every now and then, it will require extra effort in trying to get the pertinent details from the requester. That said, with that extra effort you will find satisfaction and calm knowing your environment is secure and that you are providing quality service to your customers.

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

Life Support 2008 – Audit Logons

With SQL Server 2008 and 2008R2 limping along and becoming terminally ill (End of Life Support was July 9, 2019), it should come as no surprise that it is recommended to migrate/upgrade affected databases/servers to newer technology.

Planning to upgrade/migrate requires a fair amount of prep work. Some of that prep work involves auditing your server for any users that may still be using the instance.

Where does one even begin in order to audit those logon events in SQL 2008 or 2008R2? Some may say to use a SQL Server Audit but that feature is an Enterprise only feature for 2008 and R2. If we were on a newer version of SQL Server, Extended Events would be the easy choice. Unfortunately, XE was not adequately mature on 2008 or R2. XE just doesn’t have the appropriate events to use in these versions of SQL Server. What’s left?

How about a server side trace? Yes, that was a bit difficult to say. Server side trace does have just the right events for us to use to discover who is using the server and which principals can be eradicated. A big benefit here is that a server side trace does not come with a service outage as would be required for other methods.

Server Side Trace

How do we go about creating a trace to capture these events? It is common knowledge that using a script to create a server side trace is not very intuitive. It is also not very plausible to run a Profiler session and leave it running for weeks while you do your due diligence. There is a shortcut available that allows us to run a server side trace but it does require the use of Profiler – for just a tiny bit. You can start here to find how to do that.

Great, we have a method to create the script. What needs to go into this session? Let’s take a look at that. Ignoring the initial steps to start a profiler session (other than to use a blank template), let’s jump to the event selection tab. From there, we will make two selections (Logon and Login Failed in the Security Audit section) as shown in the next image.

Once the events are selected, go ahead and click run. From there you may stop the session and then continue with the instructions from the previous link on how to script a profiler session.

After scripting this session, I get a script that looks like the following.

I created this script from SSMS 18.0 and find it interesting that the script says “Created by: SQL Server 2019 CTP2.4 Profiler”. Despite the very recent version of SSMS used to create this script, this script will work perfectly fine on SQL Server 2008 or R2.

Once I start the trace on a server, I am ready to do just a little bit more. I want to verify what this script means. Afterall, it is a bunch of numeric values. Let’s look at that with this next query and then compare it to the initial script used to create the trace. The following query requires SQL 2012 or later.

This produces output similar to the following.

As you scroll through the list, you can see the Event Name along with the column name for all events/columns that have been added to the trace. I have highlighted the first event / column mappings to illustrate this relationship.

Cool! Now, I know the session does indeed contain the requisite data that I wanted so it is time to start checking to see what is happening on the server.

Now you are all set to go to start figuring out which logins (if any) are still connecting to the server and using databases on that server.

The Wrap

This article has shown how to audit the logon events for a SQL 2008/R2 instance. It also happens to be an excellent follow up to another recent article – here. As you begin to plan your migration off of the SQL 2008 dinosaur, it is essential to baseline the activity and use of the server. This audit session will help you do exactly that!

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

Public Role Permissions – Back to Basics

Permissions in the database environment is such an important task. Setting permissions correctly is paramount to a successful audit and one of your best defenses against improper/unwanted access. Yet, in spite of the importance, security is often overlooked, neglected, improperly configured or just flat out ignored. Let’s not forget the times that security is intentionally misconfigured so certain individuals are permitted a backdoor access.

Security, just like performance tuning, is a perpetual (and sometimes iterative) task. There is no excuse for setting your security and forgetting it. It must be routinely reviewed.

While performing a script review for a client, I was reminded of the need to also review their security setup. The reminder was more of a slap in the face as I noticed that the developer had built in some permissions assignments for some upgrade scripts. Unfortunately, we were not permitted to alter any of the scripts due to them being from a third party vendor (and that vendor refused as well to fix the problems with the scripts but I digress).

What could be wrong with this?

I want you to digest that for just a moment. This is an example of the permissions this particular vendor insists on setting for the public role. What could possibly be wrong with that? Let’s examine a couple of the permissions like “Control” and “View Change Tracking”.

View Change Tracking

This permission is an elevated permission that is required in order to use the change tracking functions. This permission is necessary for the following reasons:

  1. Change tracking records contain the PK value for rows that have been deleted. If sensitive information was deleted that a user should not be able to access, the user would be able to reverse engineer the data from the change tracking data.
  2. A user may be denied access to a column that contains sensitive data. If data in the column is changed, the data would be stored in the change tracking and a user can determine the values that were updated for the sensitive data.

Control

I am going to take this one direct from the Microsoft documentation.

Confers ownership-like capabilities on the grantee. The grantee effectively has all defined permissions on the securable. A principal that has been granted CONTROL can also grant permissions on the securable. Because the SQL Server security model is hierarchical, CONTROL at a particular scope implicitly includes CONTROL on all the securables under that scope. For example, CONTROL on a database implies all permissions on the database, all permissions on all assemblies in the database, all permissions on all schemas in the database, and all permissions on objects within all schemas within the database.

Now digest that a bit. Once digested, consider what the public role does to user access in a database. The public role permissions are inherited by all users of the database whether the users have been granted the permission or not. You should only grant permissions to the public role that you really honestly believe that ALL users should have. If you are being serious in your role, then the amount of times you grant permissions to the public role should either be a) never, b) when you want to have a data breach, or c) you are testing in a sandbox to improve your skills.

Check for Perms

When you are uncertain of which permissions have been assigned to the public role, or you just haven’t reviewed your permissions real-estate in some time, it is best to pull out a script and start the process. As luck would have it, I have a few scripts that can help with that (here or here) and I have a new one that I am sharing now.

Let’s start with a basic query that will display all of the permissions assigned to the public role in a specific database.

There is nothing super special about this query. Looking at it, it is querying the permissions for the public role specifically. I display where the permission is a “Deny” or “Grant”. Then we list the permission name and then the schema and the object.

Let’s take that script and evolve it now. I am going to plan for the worst and expect that some permissions have been applied that shouldn’t have by some vendor upgrade script (because – well, history). Since I am expecting the worst, I am going to add some script generating code that will revoke the unwanted permissions. And still expecting the worst would be that revoking the permissions will break something, I will also add some code that can generate the appropriate “Grant” statements.

That looks better. I have a way of identifying the unwanted permissions as well as an easy script I can execute to remove the unwanted permissions. Note the use of the collate in the final two columns. As it turns out, permission_name from sys.database_permissions has a column collation of Latin1_General_CI_AS_KS_WS. Since I ran into some errors (shown below), it is easier to direct the DB engine to use the collation that matches the permission_name column.

Msg 451, Level 16, State 1, Line 11
Cannot resolve collation conflict between “SQL_Latin1_General_CP850_CS_AS” and “Latin1_General_CI_AS_KS_WS” in add operator occurring in SELECT statement column 5.
Msg 451, Level 16, State 1, Line 11
Cannot resolve collation conflict between “SQL_Latin1_General_CP850_CS_AS” and “Latin1_General_CI_AS_KS_WS” in add operator occurring in SELECT statement column 6.

Alas, this is still not quite as efficient of a script as I would like. I may have hundreds of databases on the instance and need to evaluate all of them. Time for the bigger guns.

That will take care of all of the permissions for the public role in all of the databases, with a slight caveat. I am only checking against that objects that are not flagged as is_ms_shipped. Now, isn’t there also a public role at the server scope? Indeed there is! Let’s also capture those permissions.

Now, I feel many times better about what could possibly be going wrong with the public role.

If you are in a tightly controlled environment or you are just sick of people doing this sort of thing to your servers, there are more extreme measures that can be taken. You can read about it here or here.

The Wrap

It is amazing what some people will do that just doesn’t make sense. Granting permissions to the public role is one of these cases. That behavior also explains why there are documents and procedures for hardening the public role (here and here).

If necessary, I recommend locking down your public role. It will make your job a little easier and give you better rest at night.

This has been another post in the back to basics series. Other topics in the series include (but are not limited to): Backups, backup history and user logins.

The Curiously Large CASE Statement



A powerful little expression in SQL Server is the CASE statement. The CASE statement has the ability to “transform” data per business rules to help better understand the data in a given query. In the simplest form, the CASE statement is a statement that evaluates a list of conditions (in order) and returns the first matching result expressions.

Most uses of the CASE statement are benign enough that one wouldn’t even bat an eye at them. Every now and again, along comes a nifty little query that contains over 300 conditions in the CASE statement. Something that extreme certainly deserves a second (third or even fourth) look. In this article, I am going to explore one such CASE statement in an effort to squeeze more efficiency out of it.

300!

300+ conditions may be a bit hard to imagine. I know I had to double take the list more than once. Immediately upon seeing such an awful piece of code (not pulling punches there), I really wanted to dump the conditions/evaluations into a table and join to it. Eventually, I did put it into a table but not before catching some metrics. Let’s take a look at what this thing looked like from the execution plan properties perspective.

In the preceding image, note the query map in the scrollbar. I have the case statement circled in green. Yes – it is really that large. Next, I have “cached plan size”, “estimated number of rows”, and “estimated subtree cost” circled in red. Each of these shows something that is a little alarming to me. First, the plan size is 48MB! Next, the cost of the query is a little elevated at 51 and change. Last is what seems to be a high value for the estimated number of rows to be returned (only ~6k actually get returned).

On the plus side, the query only takes 381ms, or does it? The query actually takes 3 seconds to complete despite the timing in the properties window. Sometimes, we have to take some of these values in the properties window with a grain of salt.

What if I try to run this query on SQL Server 2017 instead of SQL Server 2014? Let’s take a look at what that might look like.

Firstly, we have a few properties that seem to indicate that we have moved in a slightly better direction with this particular query. The cached plan size has dropped all the way down to just 37MB. The estimated cost dropped to 36 and change and the elapsed time dropped to 353ms. Nothing terribly earth shattering there – but just changing to SQL Server 2017, in this case, we see a bit of an improvement.

That said, take a look at the compile memory and compile time. Memory is 30,544kb and the time is 1,324ms. Aha – we see why this query takes 3 seconds on SQL 2014 and roughly 2 seconds on SQL 2017. High compile times. That memory for the compile is too high for my liking as well so let’s go ahead and take a look at why that might be a little high. It’s time to look at the plan XML and the converted tree for the query (because it is fun).

This is where we get a little geeky with the CASE statement. In the execution plan XML (and the converted tree we will see in a bit), every evaluation criteria for the case statement must have some sort of instruction on how and what should be done. In the case of the XML, we have multiple scalar operators to denote the CASE statement and then each of the evaluations for the CASE statement.

Once we enter the CASE statement, the first thing we see is that there is an “OR” operation (circled in red). Then for each of the values to be compared, we will see an “Equality” operation (circled in green) followed by the value to be evaluated. For just the three values I have in the image, notice how that immediately bloats the execution plan XML for this query.

In the preceding image, we see the converted tree for this query. We see the same pattern evolve here. There is a scalar operator for each value to be evaluated. In this image, I just have the equality comparisons. However, there is also an OR operator that is defined further up in this converted tree. Could this possibly be the reason for the bloated compile time and compile memory?

Let’s evolve that query just a bit and use a table and a join for that particular case statement to see what happens.

Immediately, we can see that the cached plan size improves dramatically! The cached plan size is down to 1.1MB. The compile memory is down to ~4MB and the compile time is down to 174ms. These are all significant improvements but now we see an interesting problem with the memory grant. This query is requesting over 400MB for the memory grant. That should be sounding sirens everywhere. Also of note is the estimated number of rows has dropped to ~28k (a significant improvement in estimate). This query is completing in under 1 second at this point compared to the 3 seconds otherwise but that memory grant is worrying me (and hopefully you too).

For giggles, I went ahead and added a columnstore index to this table (for good reasons beyond the scope of this article). Let’s see what that did.

Notice how the memory grant has dropped to just over 28MB? This is an acceptable improvement for this query. Also note the query execution time improved by a decent amount. This query timing for this query is similar with both a warm cache or cold cache at this point.

Remember that note about the XML and converted tree bloat? With the case statement, the query plan was in excess of 37MB and the revised version is sitting at about 1.1MB. Looking at the quantity of text in each, I see 5819 lines of XML in the version with the case statement and only 3755 lines of XML in the table version of the query (and more room for optimization). The converted tree is more dramatic in that the case statement version of the converted tree requires 3157 lines of instruction and the version that uses a table instead only has 1353 lines of instruction.

What does any of that matter? It helps to illustrate that this 300+ condition filled CASE statement is causing bloat and wasting space along with execution resources.

Wrap

If you ever find yourself writing a query that requires an excessive amount of conditions to be evaluated in a CASE statement, you should reconsider the query design. Too many conditions can lead to plan bloat and excessive memory grants. Keep an eye out for stuff like that!

Thanks for reading! This has been a pseudo deep dive into a really ugly CASE statement. If you would like to read other articles that are less of a deep dive, You can read check out the Back to Basics articles here, or the Extended Events articles here.

Defaults In msdb Database

Today is a day to discuss defaults. It started with the day being TSQL Tuesday and having a topic of “Say No to Defaults.” You can read more about that from the invite – here. I already participated in the party but did also want to discuss defaults a little bit more. That said, this article is not participating in the blog party. That would seem a bit silly.

While, this post is not a part of the party, the defaults to be discussed are fairly important. I have seen severe consequences due to these defaults being ignored and not changed. So today, in addition to my earlier article (you can read it here), I implore you to make some fundamental changes to your production servers with regards to various defaults.

A Trio of msdb Defaults

There aren’t really that many defaults within the msdb database that must be changed, are there? I mean, seriously, beyond the defaults that are available to every database, what could possibly be unique to this database that could have a severe consequence?

I am so glad you asked!

The defaults in the msdb database are more about what is missing than what is actually there. By default, this database is missing quite a few things that could be deemed critical to your environment.

Let’s start with an easy one – Indexes

There are a few out there that may disagree, but the proof really is in the effect on performance for backup jobs and such. I have three indexes I like to put on every instance. I have seen the implementation of these indexes aid in improved job times as well as aid in reduced time to “clean” up the database.

Easy enough. These indexes are very straight forward and pretty small in the grand scheme of things. But if the index can help improve performance by a factor of 10, then I am in favor of them (and I have seen that performance gain).

Now that we have some supporting indexes to help a bit with performance, we should take a look at the next item. This one can help with job performance as well as help with keeping the msdb database nice and trim.

Data Pruning

I have walked into client instances that had backup history dating all the way back to 2005 and included two-three full backups a day per database with quarter-hourly log backups. Oh and this was for an instance containing well north of 200 databases. Can you say sluggish backups and sluggish msdb overall?

The fix is very easy! Not only do I recommend pruning the backup history, but also the job history, mail history and maintenance plan history (eew – if you use those things). Think about it – do you really need to know that Job XYZ ran successfully in 2006 and only took 15 seconds? This is 2015 and that kind of data is probably not pertinent at this point.

The pruning of this data is not enabled by default! You have to configure this for each of the servers under your purview. Luckily, this is easy to do!

If you use this code sample, be sure to adjust the number of days shown in the retention to match your specific needs.

Now we have addressed a couple of defaults in msdb that can impact your performance. We are tidying up the database and in a much happier state these days. There is one more default, though, that is really critical to your data’s well being. This one is set within the msdb database but it really is for all of your databases!

Configuring Alerts!

I’m not talking about just any alerts. There are some very specific alerts that really should be configured. These are the alerts that can help you intervene to minimize corruption.

If you haven’t faced a problem with corruption – you will. It is only a matter of time. Corruption happens. When it happens, the earlier one can intervene, usually the better the outcome. Every minute counts, so why not try to reduce that time as much as possible?

This one is not terribly difficult to implement. I happen to have a query ready to go for that as well. All that needs to be done is a minor adjustment to the alert email address:

Wrap

Wow! Now there are three quick defaults that must be changed on every server. These defaults will help improve performance as well as help you stay on top of things when they start to go south (corruption). With timely notifications, and better performance, your servers will be happier, healthier, and longer lasting.

Thanks for reading! This has been another article in the Back to Basics series. You can read many more here.

Easy Permissions Audit

Categories: News, Professional, SSC
Comments: 2 Comments
Published on: January 21, 2019

Something I have written about more than a handful of times is the need to audit. When people think about audits, the first thing that comes to mind is most likely the IRS and taxes. More than taxes are audit-able. Despite that tendency to first think taxes when somebody says “audit”, I am not writing about taxes. I will typically write about the different topics within SQL Server that can be audited. Has Johnny performed a logon to the server? When was the last time the permissions to the database changed? Did somebody change an object? When was the last time stats were updated? How about auditing success and failure of your backups (or all agent jobs for that matter)? Those are the topics I will typically write about. Today, I am going to share a simple method to help perform an easy permissions audit permissions – on a manual basis.

Easy Permissions Audit

As the article title denotes, today I will be discussing a simple way to get quick permissions for various principals. If you are looking for a more comprehensive and human friendly report version, I recommend reading any of my many other articles on the topic such as the following article – here or here. In the second of those links there is a clue as to what tool we will be using in this easy version of the audit. That tool is called sp_helprotect.

The stored procedure sp_helprotect is a system stored procedure from Microsoft that can help divulge permissions for various principals in a simple table result set for you. Bearing in mind that I am keeping this to a simple audit, the examples will be simplistic in nature. Without further ado, here is the easy audit for your permissions.

sp_helprotect

This stored procedure was introduced in SQL Server 2008 and comes with a few parameters to help narrow the results down to a specific principal and even to any object to which that principal may have been granted permissions. Here are those parameters for quick review:

@name = This parameter is to filter your request down to a specific object or a statement that can be executed against that object (e.g. alter, create, drop)

@username = Is the name of the principal for which permissions are returned.

@grantorname = Is the name of the principal that granted permissions.

@permissionarea = This is the group of grant-able permissions. There are two types of groups: object and statement. The default setting here is to return both groups.

The easiest way to use sp_helprotect is as follows:

Do you see how easy that is? This returns the following results for me.

Note from the results that I see results for roles and users for various different objects. This is due to how the procedure was executed – with no parameters. Using no parameters in this query, the default behavior is to return as much information as possible for all objects and principals within the database.

What if I only want the results for a principal named “Gargouille”? I can do that in the following way.

Now, I will receive the following results:

Recap

There are many ways to produce an audit. Today, I have shown how one can produce a permissions audit when in a hurry that will produce a simple result set for database permissions. I want to underscore that this was at the database level and not the server level. While this is an adequate means for a quick peek into some of the objects and granted permissions, I do recommend using one of the other methods I have introduced in the other articles for ongoing complex audits and results that are somewhat prettier and more human friendly to read.

For more articles on audits and auditing check here and here.

«page 1 of 4

Calendar
June 2020
M T W T F S S
« May
1234567
891011121314
15161718192021
22232425262728
2930

Welcome , today is Friday, June 5, 2020
